8.4 Carrying out a one-point master
measurement
1. If necessary, return to the standard display
elements.
2. Insert the master into the measuring instru-
ment.
3. Press the MASTER key. The master nominal
value is displayed.
4. Press START. The master measurement is
started.
5. Remove the master and insert the workpiece
that is to be measured.
6. The deviation of the workpiece from the
spe cified nominal value is displayed.
8.5 Carrying out a two-point master
measurement
1. If necessary, return to the standard display
elements.
2. Insert the smaller master into the measuring
instrument.
3. Press the MASTER key. The master nominal
value of the smaller master is displayed.
4. Press START. The actual value of the smaller
master is displayed.
5. Remove the smaller master and insert the
larger master.
6. Press START again. The nominal value of the
larger master is displayed.
7. Press START again. The actual value of the
larger master is displayed.
8. Remove the master and insert the workpiece
that is to be measured.
9. Press START again. The deviation of the
workpiece from the specified nominal value
is displayed.
