53
4
Press the key.
• The scale compensation display appears.
(The right figure shows the 4-point detection display
as an example.)
5
Make setting with the jog key or
.
• Press the key to change the
display to the next scale compensation
setting.
• If [DIST.REVI.] is set to [OFF], the display for scale compensation setting will not appear.
• If [MARK DETECT] its set to [2ptA], the display for inputting the B length will not appear.
• If [MARK DETECT] is set to [1pt], the scale compensation setting display will not appear
but the origin point will be displayed.
6
Press the key after
completing the settings.
• The plotter will start detecting the
registration marks according to the settings
of [MARK DETECT].
• See "Setting the Number of Registration
Mark Detection" （ P. 44 ） for the
number of registration marks.
• In case the plotter cannot detect any registration marks, it displays “Error 36 in the
registration mark detection” on the display. Set the sheet again.
7
Set the origin.
• The display will show the available cutting
area and then return to local mode.
To Next Page
