MIMAKI CG-100SR2 User Manual

56
Cut Out Data with Registration Mark
7
Press the key.
8
Press or key to select the
scan width.
• Set values: 10 to 30cm
9
Press the key.
10
Press or key to select the
search range.
• Set values: 10 to 50cm
11
Press the key.
12
Press the
key twice for terminating this function.
• If it is not recognized as a registration mark or there is no response even if the function scans
the area set for search, the message indicating the search failure will be displayed in a
certain time.
Then, it will return to the original point and the mode will move to the normal semi-automatic
registration mark detection mode.
SCAN WI DTH
：
10cm
ENTER/HOLD
SCAN WI DTH
：
20cm
SearchRange
：
10cm
ENTER/HOLD
SearchRange
：
30cm
ENTER/HOLD
END
SEARCH FA I LED
SEARCH START POS
