Electromagnetic Compatibility Appendix
6 - 16 0070-10-0699-02 Accutorr V Operating Instructions
TABLE 6-2
GUIDANCE AND DECLARATION - ELECTROMAGNETIC IMMUNITY
The Accutorr V is intended for use in the electromagnetic environment specified in the table. The
customer or the user of the Accutorr V should assure that it is used in such an environment.
IMMUNITY
TEST
IEC 60601
TEST LEVEL
COMPLIANCE
LEVEL
ELECTROMAGNETIC
ENVIRONMENT - GUIDANCE
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines ±1
kV for input/
output lines
±2 kV for power
supply lines ±1
kV for input/
output lines
Mains power quality should be that of
a typical commercial or hospital
environment.
Surge IEC
61000-4-5
±1 kV
differential
mode ±2 kV
common mode
±1 kV differential
mode ±2 kV
common mode
Mains power quality should be that of
a typical commercial or hospital
environment.
Voltage dips,
short
interruptions and
voltage
variations on
power supply
input lines IEC
61000-4-11
<5% U
Τ
(>95%
dip in U
T
) for
0.5 cycle
40% U
T
(60%
dip in U
T
) for
5 cycles
70% U
T
(30%
dip in U
T
) for
25 cycles
<5% UT (>95%
dip in U
T
) for 5
sec.
<5% U
Τ
(>95%
dip in U
T
) for 0.5
cycle
40% U
T
(60%
dip in U
T
) for
5 cycles
70% U
T
(30%
dip in U
T
) for
25 cycles
<5% UT (>95%
dip in U
T
) for 5
sec.
Mains power quality should be that of
a typical commercial or hospital
environment. If the user of the Accutorr
V requires continued operation during
power mains interruptions, it is
recommended that the Accutorr V be
powered from an uninterruptible power
supply or a battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields
should be at levels characteristic of a
typical location in a typical commercial
or hospital environment.
U
T
is the A.C. mains voltage prior to application of the test level.
