Setting The Clock (Date and Time) Operation
3 - 40 0070-10-0699-02 Accutorr V Operating Instructions
3.14 Setting The Clock (Date and Time)
Set the clock during normal operation or in the User Configuration. See section 3.16, for
details on entering the User Configuration. There are six (6) properties to set in the clock
dialog: DATE FORMAT, YEAR, MONTH, DAY, HOUR, and MINUTE.
NOTE: The Accutorr V always displays time in a 24-hour format.
FIGURE 3-25 Example TIME SETUP Dialog
To set the time and date:
1. Press (12) to display the SYSTEM SETUP dialog as shown in FIGURE 3-7.
2. Press (16) or (19) to select TIME SETUP.
3. Once TIME SETUP is highlighted, press (18) to display the TIME SETUP dialog
as shown in FIGURE 3-25.
4. Press (16) or (19) to highlight a property to set.
5. Once the property is highlighted, press (18) to select it.
6. Press (16) or (19) to change the value in the selection.
7. Once the desired value is displayed, press (18) to set it.
8. Repeat steps 4 to 7 as needed.
9. Once the values are set, press (12) to exit to the SYSTEM SETUP dialog.
10. Press (12) to exit to the Trend display.
