Nurse Call Set-up User Maintenance
4 - 12 0070-10-0699-02 Accutorr V Operating Instructions
4.9 Nurse Call Set-up
1. If needed, press to return to the Normal display.
2. Press to display the SYSTEM SETUP dialog.
3. Press or to highlight MAINTENANCE.
4. Once MAINTENANCE is highlighted, press to display the MAINTENANCE
dialog shown in FIGURE 4-5.
5. Press or to highlight NURSE CALL.
6. Once NURSE CALL is highlighted, press to display the NURSE CALL SETUP
dialog shown in FIGURE 4-7.
FIGURE 4-7 NURSE CALL SETUP Dialog
7. Press or to highlight the SIGNAL DURATION pull-down list.
8. Once the SIGNAL DURATION pull-down list is highlighted, press to select it.
9. Press or to highlight CONTINUOUS or PULSE.
• CONTINUOUS sets the nurse call signal duration to the same as the alarm duration.
• PULSE sets the nurse call signal to a one (1) second pulse. When multiple alarms
occur, the monitor outputs only one pulse signal. If another alarm occurs before the
current alarm is cleared, the monitor will output another pulse signal.
10. Once the selection is highlighted, press to select it.
11. Press or to highlight the SIGNAL TYPE pull-down list.
12. Once the SIGNAL TYPE pull-down list is highlighted, press to select it.
13. Press or to highlight NORMAL OPEN or NORMAL CLOSE.
NOTE: SIGNAL TYPE is determined by the hospital nurse call
system.
14. Once the selection is highlighted, press to select it.
15. Press or to highlight either HIGH or LOW for ALM LEV.
16. Once an ALM LEV is highlighted, press to select it.
17. Press or to highlight either TECH or PHYS for ALM TYPE.
18. Once an ALM TYPE is highlighted, press to select it.
To Next Page
