Accutorr V Operating Instructions 0070-10-0699-02 2 - 3
Controls and Indicators Front Panel
2.2 Front Panel
FIGURE 2-1 Accutorr V Front Panel
NOTE: The numbers in parentheses ( ) refer to the items described
as follows and shown in Figures 2-1 through 2-3.
1. Alarm lamp
Flashes red for a high priority alarm and shows continuous yellow for a low priority alarm.
NOTE: In the event that a high alarm and a low alarm occur
simultaneously, only the high priority red lamp flashes.
1
2
3
4
6
7
8
5
9
12
13
14
15 18
19
20
17
16
34
31
33
29
26
25
24
32
23
2221
27
28
30
10
11
