BeneLink Module Operator’s Manual 4-75
Monitor output: alarms from MAQUET SERVO-U/SERVO-N Ventilator
Priority Label
Low
Low
Lo
w
Technical
Alarm
If the monitor shows the alarm [Low Technical
alarms], the external device has one or more of the
following alarms:
Expiratory cassette replaced
Inconsistent Edi signal
Low Edi signal
No Edi signal detected
Volume delivery restricted
4.16.3 Output Signals—Waveforms (For BeneVision N Series
Monitor Only)
The following waveforms from the external device can be output to the monitor:
 Paw
 Flow
 Volume
 CO2
4.16.4 Output Signals—Respiratory Loops (For BeneVision N
Series Monitor Only)
The following respiration loops from the external device can be output to the
monitor:
 PV Loop
 FV Loop
 PF Loop
