BeneLink Module Operator’s Manual 4-59

Monitor output: alarms from Hamilton G5 (Block Protocol) Ventilator

Priority Label

Low

Technical

alarm

Ventilation adjustment OFF (no PetCO2)

Check CO2 sampling line

Check INTELLiVENT PEEP limit setting

Set low limit of ExpMinVol alarm

Recruitment in Progress

Oxygenation Controller on Limit

Ventilation Controller on Limit

SBT conditions fulfilled

SBT in progress

4.12.3 Output Signals - Waveforms (For BeneVision N Series

Monitors only)

The following waveforms from the external device can be output to the monitor:

 Paw

 Flow

 Volume

 CO2

4.13 Hamilton G5 (Polling Protocol)

4.13.1 Output Signals – Parameters

Monitor output: parameters from Hamilton G5 (Polling Protocol) Ventilator

Label Description Trend, record, print

Monitoring Parameters

O2% Oxygen concentration Yes

MV Minute volume Yes

I: E Inspiratory time:Expiratory time ratio No
