4-54 BeneLink Module Operator’s Manual
Monitor output: parameters from Hamilton G5 (Block Protocol) Ventilator
Label Description Trend, record, print
Pinsp Pressure control level of inspiration No
Phigh Upper pressure level No
F-Trigger
Inspiratory trigger
level (flow trigger)
No
I:E Inspiratory time:Expiratory time ratio No
Peak Flow Peak flow No
Exp% Inspiration termination level No
Ramp Ramp No
IBW Ideal body weight No
%MinVol
Percentage of minute volume to be
delivered
No
Tlow Time for the lower pressure level No
Thigh Time for the upper pressure level No
Ti max Maximum inspiration time No
Tip Inspiratory pause time No
tube ID Tube ID No
base flow Base Flow No
O2% Oxygen concentration No
4.12.2 Output Signals – Alarms
Monitor output: alarms from Hamilton G5 (Block Protocol) Ventilator
Priority Label
Physiological alarms
High
Paw Paw High
Paw Low
FiO2 High
FiO2 Low
