4-16 BeneLink Module Operator’s Manual

Monitor output: alarms from Draeger Babylog VN500 Ventilator

Priority Label

Low

Technical

Alarms

CO2 measurement failed

CO2 sensor ?

Plow>high limit

Plow<low limit

4.5 Draeger Evita 2

4.5.1 Output Signals – Parameters

Monitor output: parameters from Draeger Evita 2 Ventilator

Label Description Trend, record, print

Monitoring Parameters

O2% Oxygen concentration No

PEEP Positive end-expiratory pressure Yes

Ppeak Peak pressure Yes

Pplat Plateau pressure Yes

Pmean Mean pressure Yes

VTe Expiratory tidal volume Yes

MV Minute volume Yes

MVspn Spontaneous breathed minute volume Yes

ftot Total respiratory rate Yes

fspn Spontaneous breathing frequency Yes

FiO2

Fractional concentration of O

in inspired

gas

Yes

Rdyn Dynamic lung resistance Yes

Cdyn Dynamic compliance Yes

Pmin Minimum airway pressure No

Vtrap Trapped volume No

T Inspiratory breathing gas temperature No
