2-8 BeneLink Module Operator’s Manual
2.6 Connecting External Devices
The external devices are connected with the BeneLink module through an ID adapter,
which supports only its matching device. Please refer to the following procedure to
connect an external device:
(1) BeneLink module (2) Label
(3) RJ45 connecting cable
(4) ID adapter
(5) External device (6) Serial port adapting cable (optional)
1. Ma
ke sure that BeneLink module contains the device drivers which match the
devices you want to connect.
For BeneVision N Series monitor, to check the installed device drivers,
select the [Main Menu] quick key from the [System] column, select
[Maintenance] → input required password → select [Ok] → select the
[Version] tab, check [BeneLink Module Version]. If desired device
drivers are not installed, contact Mindray service to inquire about
solutions.
For Passport 12m/17m, to check the installed device drivers, contact
Mindray service.
(3)
(5)
To Next Page
