3-18 BeneLink Module Operator’s Manual
Monitor output: alarms from Draeger Perseus A500 anesthesia machine
Priority Label
Me
dium
ABS.PRESENT?
HOSES MIXED?
WRONG HOSES?
AIR ENTRAIN
VENT PAUSE?
CO2
Module
abnormal
If the monitor shows the alarm [CO2 Module
abnormal], the external device has one or more of
the alarm: CO2 LINE BLK
AG
Module
abnormal
If the monitor shows the alarm [AG Module
abnormal], the external device has one or more of
the following alarms:
MIXED AGENT
CO2 AGT ERR
2nd AGENT
WATERTR.OLD?
Low
Low
Technical
Alarm
If the monitor shows the alarm [Low Technical
alarms], the external device has one or more of the
following alarms:
RS232COM ERR
PRESS ERR
WATER TRAP ?
VENT TEMP HI
VOL ERR
FAN ERR
N
2
O PRESS HI
O2 CYL. ?
VOLAT SUPPLY
CO2-LINE ?
PWR SPLY ERR
