Mindray DC-70 Service Manual

8-16 Field Replaceable Unit
No. Order Number Part Name Qty. Remark
E1 043-009176-00 fixing loop(2143) 1
E2 044-000742-00 host handle 1
E3
115-050641-00
Top cover assembly(2143)
1
E4 115-050644-00 Back cover assembly(2143) 1
E5 115-025799-00 Right Cover Assembly(FRU) 1
E6 115-041686-00 Left Cover Assembly(2123,CE&FDA,FRU) 1
E7 115-052373-00 Front-in Assembly(2145/FRU) 1
E8 043-009175-00 printer Cover(2143) 1
E9 115-052366-00 Front cover assembly(2145/FRU) 1

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
