Mindray DC-70 Service Manual

Structure and Assembly/Disassembly 9-1
9 Structure and
Assembly/Disassembly
9.1 Structure of the Entire System
No. Name No. Name
<1>. Touchscreen assembly <2>. Right side-panel assembly of main unit
<3>. Top cover assembly of the control panel <4>. Keyboard assembly
<5>.
Printer cover
<6>.
Rear cover assembly of main unit
<7>. Cast-aluminum base <8>. Main body and keyboard assembly
<9>. Speaker assembly
<10>
Left side-panel assembly of main unit

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
