Mindray DC-70 Service Manual

System Installation 3-5
5. Release the buckle. Take the plastic bag out as shown in the figure below:
6. Remove the front panel in the direction of the arrow, and then get out the device.
3.2.2 Check
1. After unpacking, check the objects in the container with the package list to see if anything is in
short supply or is wrong.
2. Ensure there is no damage, indentation or cracks occurring to the machine. If any, please
contact Mindray Customer Service Department.
3.3 Installation of Main Unit
NOTE:
To prevent the machine from damage, when you perform the following operations,
please lock the casters if the machine doesn’t to be moved

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
