Mindray DC-70 Service Manual

Field Replaceable Unit 8-19
No. Order Number Part Name Qty. Remark
E12-1 115-051521-00 IO Board Assembly(FRU) 1
E12-2
115-051210-00 WIFI Module Kit(EWM-W163M201E) 1
Including Wi-Fi card and the Wi-Fi antenna.
For upgrade use
023-001528-00 Wi-Fi module Wi-Fi + BT 1 Only Wi-Fi card. For repair.
E12-3 024-000965-00 M.2 port wifi antenna 1 Including one Wi-Fi antenna
E12-3
E12-2
E12-1

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
