Mindray DC-70 Service Manual

Troubleshooting of Regular Malfunctions 13-11
error of ECG module or circuit error of
ECG serial port for signal processing
board may also occur. The possibility of
the error for ECG module is
comparatively higher.
module;
Check ECG connection cable
or replace ECG assembly.
2 Enable ECG.
The waveform
of ECG appears
as a signal line
or the shape of
the wave is
abnormal.
Abnormal ECG lead or ECG module Self test for ECG module;
Replace ECG lead or ECG
module.

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
