Mindray DC-80 User Manual

Image Optimization 5-45
MPR Only
Touch on the touch screen to display MPR only. And the adjustable image parameters are
changed into MPR parameters automatically.
Only A, B and C MPR are displayed, and VR is not displayed.
MPR Only function is available in image acquisition status.
Asymmetric
Touch on the touch screen to display MPR along with VR. It will represent you with a larger
VR image along with 3 small MPR images.
View Direction
The Region of Interest (ROI), also referred to as the Render Box in rendering, contains the section
of the volume you want to render. Therefore, objects that are not inside of the box are not included
in the render process and are cut out (this is important in surface mode to allow a free line of sight).
This may or might not be the entire VOI.
You can adjust the view direction of the ROI.
a
b
Sectional A
Sectional B
Sectional C

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
