Mindray DC-80 User Manual

5-70 Image Optimization
5.10.12 iLive
iLive brings you a better imaging experience by adding light rendering effect to the traditional way.
It supports global lighting mode as well as partial scattering mode, allowing human tissue texture to
be revealed more clearly.
iLive is an option, it is available under Smart 3D, Static 3D and 4D mode. To use iLive function, you
also have to firstly configure Smart 3D module or 4D module.
 To Activate iLive
1. Enter 3D/4D image viewing status; or double-click the saved 3D/4D cine file in iStation or
Review screen.
2. Touch the [iLive] on the second page of the touch screen to turn on the function, adjust
parameters.
 Imaging using iLive
1. Select the imaging mode:
 Use 2D ordinary probe and press to enter Smart 3D;
 Or, use D7-2E, D8-2E, D6-2NE, DE11-3E or DE10-3E probe and press or
to enter 4D mode or Static 3D mode.
2. Select render mode to be iLive by touching the touch screen, and set related parameters
(quality and angle etc.).
3. Press <Update> to start acquisition.
4. The system finishes acquisition and enters image viewing screen.
5.
In image review status, you can perform operations like VOI setting, image editing, comment
adding, body mark adding and etc. For details, please refer to ―5.10.3.3 Static 3D Image
Viewing‖.
6. Or press <B> or / to exit the mode.

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
