Mindray V12 User Manual

Print Setup Reports
20 - 4 V Series Operating Instructions
20.2.3 Configuring the Waveforms to Print
1. Select the Print tab from the Navigation Area.
2. Select the Print Setup button.
3. Select the Configure Waveforms button.
The Waveform Configuration dialog displays (as shown in FIGURE 20-2).
FIGURE 20-2 Example Waveform Configuration Dialog
4. Navigate in this dialog by using the buttons described in TABLE 20-2.
TABLE 20-2
BUTTON DESCRIPTION
Add Adds the highlighted parameter(s) to the Selected list (located on the
right side of the dialog).
NOTE: Multiple parameters may be
highlighted in the list before
selecting the button.
Remove Removes the highlighted parameter(s) from the Selected list and
moves them to the Choices list.
Remove All Removes all the selected parameters from the Selected list and moves
them to the Choices list.
Move to Top Moves the selected parameter to the top position in the Selected list.
Move Up Moves the selected parameter up one position in the Selected list.
Move Down Moves the selected parameter from the Selected list down one
position.

Mindray V12 Specifications

General

Brand	Mindray
Model	V12
Category	Medical Equipment
Language	English
