Impedance Respiration Performance Product Specifications
29 - 28 V Series Operating Instructions
• Arrhythmia analysis is disabled in neonatal mode.
• Non-lethal arrhythmia alarms can be disabled.
• All arrhythmia alarms can be disabled unless locked by a password protected setting.
The ECG module has ability to make following calls as applicable per ECG source:
• Asystole
• Bigeminy
•QTc
•Couplet
• Irregular Heart Rate
•Multiform PVC
•Pause
• Pause/Minute
•R-On-T PVCs
•PVCs/Minute
•Run
•Trigeminy
• Ventricular Fibrillation
• Ventricular Rhythm
• Ventricular Tachycardia
29.3 Impedance Respiration Performance
V 12/V 21 in conjunction with:
A. VPS for impedance respiration
1. Performance:
TABLE 29-27
Sensing Lead: Lead II or I
Default Sensing Lead: Lead II
Source: When using a 3-Lead, 5-Lead, the respiration system acquires
respiration via the ECG leads.
Range: ECG Respiration parameter range is 4 RPM to 199 RPM.
Respiration Rate Out of Range: The respiration rate counter indicates invalid (- -) for values outside
specified range.
Accuracy: ECG Respiration parameter accuracy is greater of ± 2 RPM or 2% of the
signal value within the range of 4 to 150 RPM. ECG Respiration
parameter accuracy is ± 4% of the signal value within the range of 151
to 199 RPM.
Excitation Frequency: 38.4 kHZ
Excitation Current: < 384 µA RMS max
