Mindray V12 - VPS Physical Views

V Dock Physical Views General Product Description
1 - 12 V Series Operating Instructions
1.4.4 VPS Physical Views
Side View
1. IBP (P1-P2) connector
2. Non-invasive blood pressure (NIBP)
3. SpO
2
connector
4. ECG/EKG connector
5. Temperature (T1) connector
6. Release lever
7. Analog output protective door (2 analog outputs)
FIGURE 1-10 Example Nellcor VPS Side View
2
3
1
1
4
5
