BIS Dialog Bispectral Index (BIS) (Optional)
19 - 6 V Series Operating Instructions
FIGURE 19-4 Example Tile Setup Dialog
4. Use the buttons described in TABLE 19-2 to navigate in this dialog.
5. Select the Cancel or Accept button.
•The Cancel button closes the dialog without saving the settings.
•The Accept button saves the settings and closes the dialog.
19.2.6 Configuring the EEG Waveform
• Select the BIS digital tile.
OR
1. Select the Setup tab from the Navigation Area.
2. Select the Parameters button.
TABLE 19-2
BUTTON DESCRIPTION
Add All Add all the parameters on the left side of dialog to the Selected list (located on the right side
of the dialog).
Add Adds the selected parameter(s) to the Selected list.
NOTE: Multiple parameters may be selected from the
Choices list.
Remove Removes the selected parameter(s) from the Selected list.
Remove All Removes BC, ASYM, SEF, TP, sBIS, and sEMG from the Selected list and moves them to the
Choices list (located on the left side of the dialog).
