Digital Tiles Continuous Cardiac Output (CCO) & Continuous Hemodynamics (Optional)
1 - 12 Addendum to V Series Operating Instructions
1.4.8 Message Area
The message area provides information about the current state of the CCO STAT parameter. If there is
more than one message to display, the messages scroll.
1.4.9 Hemo Digital Tile Layout
The Hemo digital tile displays:
1. Tile name
2. Message area
3. Parameters (display up to six (6) of the following parameters):
MESSAGE DETAILS
CCO STAT High Alarm
Vio
lation
Indicates that the current value is either equal to or higher than the set alarm
limits.
CCO STAT Low Alarm
Vio
lation
Indicates that the current value is either equal to or lower than the set alarm
limits.
CCI STAT High Alarm
Vio
lation
Indicates that the current value is either equal to or higher than the set alarm
limits.
CCI STAT Low Alarm Violation Indicates that the current value is either equal to or lower than the set alarm
limits
.
T Blood High Alarm Violation Indicates that the current value is either equal to or higher than the set alarm
limits
.
T Blood Low Alarm Violation Indicates that the current value is either equal to or lower than the set alarm
limits
.
SVR High Alarm Violation Indicates that the current value is either equal to or higher than the set alarm
limits
.
SVR Low Alarm Violation Indicates that the current value is either equal to or lower than the set alarm
limits
.
SVRI High Alarm Violation Indicates that the current value is either equal to or higher than the set alarm
limit
s
.
SVRI Low Alarm Violation Indicates that the current value is either equal to or lower than the set alarm
limit
s
.
