29 - 4 V Series Operating Instructions
29.1.2 V 12 Safety Designations:
ISO 80601-2-55:2011 Medical electrical equipment - Part 2-55: particular
requirements for the basic safety and essential performance
of respiratory gas monitors
TABLE 29-1
TABLE 29-2
Type of protection against electric shock: Class II with internal electric power source. Where the integrity
of the external protective earth (ground) in the installation or
its conductors is in doubt, the equipment shall be operated
from its internal electric power source (batteries).
Supply Connection: 14.3Amps (max), +15Vdc Input
11.1 VDC Removable Battery
3.7 VDC Internal Backup Battery
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient
Equipment designed for direct electrical and non-electrical
connection to the patient
Degree of Mobility: Portable
Maximum Size: 13.7"H x 9.4"W x 7.5"D
Maximum Weight: 8.9 lbs. (without batteries)
13.00 lbs (monitor with three (3) batteries, and VPS
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- Touchscreen
1- 12.1" TFT Display
2- Alarm LED
Display Operates in portrait orientation
Minimum +50/-50 degree horizontal viewing angle
Minimum +45/-45 degree vertical viewing angle
Aspect ratio of 3:4 in portrait mode
Display resolution is 1024 x 768 pixels
Interfaces: 1- Diagnostic Port (DP1)
1- V Dock Interface (D1)
1- V Hub Interface (MR4)
3- Battery Interface (1, 2, 3)
6 - Module bays (M1-M6)
