V Series Operating Instructions 29 - 9
Product Specifications Specifications
29.1.8 CO Module Safety Designations:
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing.
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- LED, Powered and Communicating
Interfaces: 1- 12 Lead Yoke Cable
1- VPS ECG Interface Cable
TABLE 29-7 (Continued)
TABLE 29-8
Type of protection against electric shock: Class II
Degree of protection against electric shock: Cardiac Output - Type CF defibrillation protected
Supply Connection: +12VDC, +5VDC from Module Bay
Mode of Operation: Continuous
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient:
Equipment designed for direct electrical connection to the
patient
Degree of Mobility: Portable
Maximum Size: 0.988"H x 6.2"W x 5.5"D
Maximum Weight: 0.74 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- Button, Start CO Run
1- LED, Powered and Communicating
Interfaces: 1- CO
1 - Module Bay (Mx)
