V Series Operating Instructions 29 - 11
Product Specifications Specifications
29.1.10 IBP Module Safety Designations:
29.1.11 Temp Module Safety Designations:
TABLE 29-10
Type of protection against electric shock: Class II
Degree of protection against electric shock: IBP- Type CF defibrillation protected
Mode of Operation: Continuous
Supply Connection: +12VDC, +5VDC from Module Bay
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient
Equipment designed for direct electrical and non-
electrical connection to the patient
Degree of Mobility: Portable
Maximum Size: 0.988“H x 6.2”W x 5.5”D
Maximum Weight: 0.75 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- Button, Zero IBP
1- LED, Powered and Communicating
Interfaces: 2- IBP
1- Module Bay (Mx)
TABLE 29-11
Type of protection against electric shock: Class II
Degree of protection against electric shock: Type CF defibrillation protected
Mode of Operation: Continuous
Supply Connection: +12VDC, +5VDC from Module Bay
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids: Drip-proof (IPX1)
Degree of electrical connection between equipment
and patient:
Equipment designed for direct electrical and non-
electrical connection to the patient
Degree of Mobility: Portable
