V Series Operating Instructions 29 - 13
Product Specifications Specifications
29.1.13 VDI Safety Designations:
Controls/Indicators: 1- LED, Powered and Communicating
1- Button, Recorder Door Release
1- Button, Print
Interfaces: 2- Mx & My Module Bay Connectors
TABLE 29-12 (Continued)
TABLE 29-13
Type of protection against electric shock: Class II
Degree of protection against electric shock: Not protected (Ordinary)
Mode of Operation: Continuous
Supply Connection: +12VDC, +5VDC from Module Bay
Protection Against Hazards of Explosion: Not protected (Ordinary)
Protection Against Ingress of Liquids: Drip-proof (IPX1)
Degree of electrical connection between
equipment and patient:
None
Degree of Mobility: Portable
Maximum Size: .996“H x 6.2”W x 5.5”D
Maximum Weight: .68 lbs.
Operating Temperature: +5°C to +40°C
Operating Humidity: 15% to 95%, non-condensing
Operating Altitude: 1060hPa to 700hPa
Storage Temperature: -20°C to +60°C
Storage Humidity: 10% to 95%, non-condensing
Storage Altitude: 1060hPa to 570hPa
Controls/Indicators: 1- LED, Powered and Communicating
Interfaces: 1- Mx Module Bay Connector
1 - DB-9 Male Interface Connector
