V Series Operating Instructions 2 - 7
Getting Started Main Display
Start/Stop NIBP Starts/Stops a NIBP measurement in progress. If there is no measurement in progress,
the button reads Start NIBP. If there is a measurement progress, the button reads
Stop NIBP.
NIBP Stat Starts a continuous NIBP measurements for a maximum of five (5) minutes or 10
measurements.
Zero All IBP Sets the current pressure for all invasive pressure channels to zero.
View All ECG Displays all the ECG waveforms available based on the lead set currently in use.
Lead/Size Accesses the Lead/Size dialog used to change the ECG waveform height or wave
gain.
Standby Places the monitor in the Standby mode.
PRINT TAB
Continuous/Abort Begins/ends strips from printing to the thermal printer.
Print 12 Lead Prints a 12 Lead Report to the default printer.
NOTE: The Print 12 Lead button is only available in
the Print tab when 12 Lead is selected from
the ECG Cable Type button on the ECG Setup
tab.
Print Setup Accesses the Print Setup dialog where the clinician can configure which waveforms
to print and where to print them.
Print Queue Accesses the Print Queue dialog.
SETUP TAB
Patient Info Accesses the Patient Info dialog.
Audio Levels Accesses the Audio Levels dialog.
Display Accesses the Display Setup dialog.
Parameters Accesses the Parameter dialog.
System Accesses the System Setup dialog.
TOOLS TAB
Calculators Accesses the Calculators dialog.
Alarm Watch Accesses the Alarm Watch dialog.
Remote View Accesses the Remote View dialog.
System Information Accesses the System Information dialog.
VAccess Accesses the VAccess dialog.
NOTE: The VAccess button is only available in the
Tools tab if it is enabled in System Setup.
PROCEDURES TAB
NOTE: These buttons are only available when using
the Adult or Pediatric patient size.
C.O. Run Accesses the Cardiac Output Runs dialog.
TABLE 2-2 (Continued)
BUTTON DESCRIPTION
