TX3 Telephone Access System Installation and Operation Manual 5
List of Figures
Figure 1 TX3-200-8U-C, TX3-1000-8U-C, TX3-2000-8U-C,
TX3-120U-C Dimensions 19
Figure 2 Dimensions of TX3-UFT and the Universal enclosure 20
Figure 3 Mounting TX3-UFT Universal Series Flush Trim Ring 20
Figure 4 TX3-200-4U-C, TX3-1000-4U-C, TX3-2000-4U-C
Dimensions 23
Figure 5 Dimensions of TX3-USFT and the Universal Slim-line
enclosure 24
Figure 6 Mounting TX3-USFT Slim Line Universal Flush Trim
Ring 24
Figure 7 TX3-200-8C-C, TX3-1000-8C-C, TX3-2000-8C-C,
TX3-120C-C Dimensions 25
Figure 8 Mounting the Continental enclosure 26
Figure 9 Heater TH-102 Installation Location 27
Figure 10 Single Lobby Control Unit 29
Figure 11 Single Lobby Control Unit with ADC and NSL Lines 30
Figure 12 Single Entrance System Wiring 31
Figure 13 Dual Lobby Control Units 32
Figure 14 Multiple Lobby Control Units to Multiple Lines 33
Figure 15 Many Lobby Control Units to One Line 34
Figure 16 TX3 devices on an RS-485 network. 35
Figure 17 TX3 devices on an Ethernet TCP/IP network. 35
Figure 18 Lobby control units using both Ethernet and RS-485
networks 36
Figure 19 Lobby Control Unit Wiring 37
Figure 20 Lobby Control Unit Main Controller Board 39
Figure 21 Controller Board Connectors - Bottom 41
Figure 22 Tamper Switch 42
Figure 23 RS-485 Wiring 44
Figure 24 Power Supply 45
Figure 25 Controller Board Connectors - Top 46
Figure 26 Main Door Dry Contact Wiring 48
Figure 27 Modem Module Telephone Connectors 49
Figure 28 IP Module Data and Ethernet Connectors 50
Figure 29 RS-485 Add-on Module 51
Figure 30 Guard Phone Module 53
Figure 31 NSL Relay Cabinet 61
Figure 32 TX3-NSL-8M Relay Control Unit 63
Figure 33 NSL Expanders 65
Figure 34 TX3-NSL-8M Main Controller Board 66
Figure 35 NSL System with Telephone Line 68
Figure 36 NSL Controller Telephone Lines 69
Figure 37 NSL Backplane 71
Figure 38 ADSL-100 Filter Module Installation 72
Figure 39 Backplane Number Section 73
Figure 40 2012 NSL Relay Board 76
Figure 41 CA-71A BIX Block Wiring Configuration 77
Figure 42 RJ-71C Punch-Down Block Wiring Configuration 80
Figure 43 Remove the 2 screws 85
Figure 44 Install TX3-P300-HA 86
