Mitel 3300 - Group Paging and Meet Me Answer

Hardware Technical Reference Manual
28
Table 5: 10/100/1000 Ethernet Port Pin Allocation (CX/CXi, MXe/MXe Server)
Pin Number
Signal
10/100 Mode
Signal
1000 Mode
Pin Number
Signal
10/100 Mode
Signal
1000 Mode
1 TX+ TRD0+ 5 – TRD2-
2 TX- TRD0- 6 RX- TRD1-
3 RX+ TRD1+ 7 – TRD3+
4 – TRD2+ 8 – TRD3-
