10
M
ODELS AND PART NUMBERS
CHAPTER 2 ABOUT EX CONTROLLER
Optional Accessory
A Linux-compatible USB audio is required to support an external Music on Hold source. Mitel recom-
mends using Pluggable USB Audio Adapter. The USB audio can be plugged into, USB1 or USB2 port of
the EX Controller.
Models and Part Numbers
The following table describes the supported EX Controller models and their part numbers.
The following table describes the supported telephony cards for an EX Controller.
Specifications
Operating Environment
• Operating temperature range 0 °C (0 ° F) to +40 °C (104 ° F)
• Humidity maximum 85% and non-condensing
Storage Temperature
-20 °C (-4 °F) to +70 °C (158 °F)
Part Number Model
50008229 EX Controller with 4 GB RAM and 60 GB storage
50008230 EX Controller with 8 GB RAM, 120 GB storage, and Dual PSU
Part Number Telephony Card
50008234 DSP card
50008233 one Port PRI card
50008231 Four Port FXS card
50008232 Four Port FXO card
