CHAPTER 3 HARDWARE INSTALLATION
Hardware Installation
Overview
This chapter describes the following procedures that must be performed sequentially to complete the
hardware installation:
1. Installing the EX Controller
2. Installing Telephony Cards
3. Cabling
Package Checklist
Requirements
Location
• Install the controller:
– In a standard 48.26 cm (19 in.) equipment rack
– On a flat surface (such as a desk or a table)
• Do not install the controller in a location exposed to direct sunlight or near stoves or radiators. Exces-
sive heat could damage the internal components.
• The controller should be positioned to be accessible for future upgrade, maintenance, and trouble-
shooting and where cables can be easily connected.
• Maintain a minimum of 25 mm (1 in.) clearance in the front, back, on top, under, and on sides of the
controller.
Item Condition
EX Controller (Qty 1)
Power cord with the proper model for the country (Qty 1)
*
*
Qty 2 for EX Controller with dual power supply unit.
Chassis rack mounting bracket (Qty 2)
Chassis rack mounting bracket screws (Qty 2)
Ethernet patch cable, CAT-5E, 7 feet (Qty 1)
Polyurethane self-adhesive black cylindrical bumper (Qty 1)
EX Controller and GX Gateway Safety Instructions document (Qty1)
