CHAPTER 7 APPENDIX A: ASSIGNING A STATIC IP ADDRESS TO THE EX CONTROLLER DEPLOYMENT TOOL MANUALLY
Appendix A: Assigning a Static IP Address
to the EX Controller Deployment Tool Manu-
ally
If a DHCP server is not available on the network on which you want to deploy the EX Controller or if you
are unable to access the Deployment Tool using a DHCP server, then you can access the Deployment
Tool by assigning a static IP address to the Deployment Tool.
Prerequisites
• An RJ45 Ethernet cable for connection between the EX Controller and Layer2 switch.
• Download and install the latest version of UltraVNC Viewer (or VNC Viewer) application installed on
the deployment PC.
Assigning a static IP address manually
To manually assign a static IP address to the Deployment Tool:
1. Assign a static IP address to your deployment PC using the following IP scheme:
– IP address: 192.168.0.100
– Subnet mask: 255.255.255.0
– Gateway IP address: 192.168.0.1
2. Power on the EX Controller.
3. Connect an RJ45 Ethernet cable from the deployment PC’s Ethernet interface to one of the ETH2 -
ETH5 ports of the EX Controller.
4. From the deployment PC, start UltraVNC Viewer.
