Planning and Installation Guide Mitel SIP-DECT Multi-Cell for MiVoice Connect
26
7. Refresher: The refresher setting decides if user agent client or user agent server
refreshes the session. There is no need to modify the default value of “Caller (UAC).”
8. Click Save.
CONFIGURING SITE SETTINGS
The Mitel Administrator can designate up to two Proxy switches per site for
redundancy and reliability: one switch is assigned as the primary Proxy server,
and the other switch acts as the backup Proxy server in case the primary fails. A
Virtual IP Address is the IP Address of the switch that is configured as the SIP
Proxy server for the Site. The Virtual IP Address must be static. If you choose not
to define a “Virtual IP Address,” you can only define one proxy switch, and there
will be no redundancy or failover capabilities. The switches available in the “Proxy
Switch 1 / 2” will only be shown if proxy resources have been enabled on the
switch.
To configure site settings:
1. Open a browser and navigate to http://<Server name or IP address>/
Director/login.asp to launch Mitel Connect Director.
2. Navigate to Administration > System > Sites.
3. Select the name of the Site in which SIP Proxies will be assigned.
4. In the General Tab, set Proxy switch 1: Select the Mitel switch configured with SIP
Proxies for the Site.
5. Click Save.
INTEGRATING MIVOICE CONNECT WITH SIP-
DECT MULTI-CELL SYSTEM
PREREQUISITES
Before you integrate MiVioice Connect with the SIP-DECT Multi-Cell system,
ensure the following prerequisites are met:
1. Local DECT Base Station Configuration (OM Configurator) is installed. See
section 5 of the SIP-DECT OM System Manual Administration Guide
.
2. You can log in to OMM WEB Service. See section 6 of the SIP-DECT OM System
Manual Administration Guide.
3. OM Management Portal (OMP) is installed. See section 7 of the SIP-DECT OM
System Manual Administration Guide.
4. Conferencing on SIP-DECT is set up. See the Setting up conferencing for SIP-DECT
Multi-Cell system on MiVoice Connect section. For more information on
conferencing, see the Integrated Conference Server (ICS) section of the SIP-DECT
OM System Manual Administration Guide.
