Special relay and special register used in the memory dump
function
For details, refer to the following.
• Special relay: Special relay relating to the memory dump function ( Page 825 Memory dump function)
• Special register: Special register relating to the memory dump function ( Page 869 Memory dump function)
Precautions for the memory dump function
This section describes precautions to take when using the memory dump function.
Mutual exclusion of the memory dump function
The mutual exclusion of the memory dump function is as follows.
The following table lists the cases when another function is executed during the execution of the memory dump function
*1
.
*1 The state where the memory dump function is in execution includes the memory dump status of "Collecting after trigger" or the save
status of "Saving in progress".
*2 The memory dump function is not included.
The following table lists the cases when the memory dump function is executed during the execution of another function.
*3 The memory dump function is not included.
Function that has been
already executed
Function to be
executed later
Behavior
Memory dump function CPU module data backup
function
The CPU module data backup function cannot be executed while memory dump is being
registered/cleared.
CPU module data restoration
function
The CPU module data restoration function cannot be executed while a memory dump file
or memory dump setting file is being read or memory dump is being registered/cleared.
iQ Sensor Solution data
backup/restoration function
The iQ Sensor Solution data backup/restoration function cannot be executed while
memory dump is being registered/cleared.
Function specified in the
internal buffer capacity
setting
*2
If the internal buffer capacity setting is changed to execute the subsequent function,
attempting to start the subsequent function results in an error. The memory dump
continues to function normally.
Function not specified in the
internal buffer capacity
setting
If the condition "Total capacity that is set in the internal buffer capacity setting + Internal
buffer capacity that is set in other than the internal buffer capacity setting > 3072K bytes"
is satisfied, attempting to start the subsequent function results in an error. The memory
dump continues to function normally.
If the internal buffer capacity setting is changed to execute the subsequent function,
attempting to start the subsequent function results in an error. The memory dump
continues to function normally.
Function that has been
already executed
Function to be
executed later
Behavior
CPU module data backup function Memory dump function While the CPU module data backup function is being executed, memory dump cannot be
registered/cleared.
CPU module data restoration
function
While the CPU module data restoration function is being executed, a memory dump file or
memory dump setting file cannot be read or memory dump cannot be registered/cleared.
iQ Sensor Solution data backup/
restoration function
While the iQ Sensor Solution data backup/restoration function is being executed, memory
dump cannot be registered/cleared.
Function specified in the internal
buffer capacity setting
*3
If the internal buffer capacity setting is changed to execute memory dump, attempting to
start memory dump results in an error. The function already in execution continues to
function normally.
Function not specified in the
internal buffer capacity setting
If the internal buffer capacity setting is changed to execute memory dump, attempting to
start memory dump results in an error. The function already in execution continues to
function normally.
