35 BASIC CONCEPT
35.11 Memory Specifications
Files
This section lists the files used by the SIL2 Process CPU.
File types and storage memory
The following table summarizes the types of files stored in the SIL2 Process CPU and storage memory.
: Required, : Can be stored, : Cannot be stored
*1 mmm represents the start I/O number (first three digits in four-digit hexadecimal representation) of each module. For the SIL2 Process
CPU, it will be 3FFH. Also, nn represents the consecutive number (two-digit hexadecimal representation) of module extension
parameter files of each module.
*2 Can be stored but cannot operate as a function.
*3 When this file is stored in the built-in memory of the SIL2 Process CPU, it is divided into program memory and data memory and stored.
( Page 106 Configuration of a program file)
*4 Module extension parameter for the protocol setting, storing protocol setting information in the predefined protocol support function
*5 One or more of either standard program or safety program is required.
*6 The file is also stored in the SIL2 function module.
*7 This parameter relates to safety control inside the CPU parameters. ( Page 936 Safety CPU parameters)
This item is yellow in the engineering tool CPU parameters.
*8 The module-specific backup parameter is a file for storing the save or restore data of the module to be replaced by the online module
change function. For details, refer to the manual for the module used.
File type CPU built-in memory SD memory
card
File name and
extension
Program
memory
Device/label
memory
Data
memory
Drive 0 Drive 3 Drive 4 Drive 2
Standard program 
*3*5

*3*5
 ANY_STRING.PRG
Standard FB file 
*3

*3
 ANY_STRING.PFB
Standard CPU parameter CPU.PRM
System parameter SYSTEM.PRM
Standard module parameter UNIT.PRM
Module extension parameter  • UEXmmmnn.PRM
*1
• UEXmmm00.PPR
*4
Module-specific backup parameter
*8
UBPmmmnn.BPR
Memory card parameter MEMCARD.PRM
Device comment ANY_STRING.DCM
Device initial value ANY_STRING.DID
Standard global label setting file GLBLINF.IFG
Label initial value file Global label initial value
file
GLBLINF.LID
Local label initial value
file
PROGRAM_NAME.LID
File register 
*2
ANY_STRING.QDR
Event history EVENT.LOG
Device data storage file 
*2
DEVSTORE.QST
General-purpose data ANY_STRING.CSV/BIN
Remote password 00000001.SYP
Safety program
*6

*3*5

*3*5
 ANY_STRING.SPG
Safety FB file
*6

*3

*3
 ANY_STRING.SPB
Safety CPU parameter
*6*7
CPU.SPR
Safety module parameter
*6
UNIT.SPR
Safety global label setting file
*6
GLBLINF.SIF
Standard/safety shared label setting file
*6
S_GLBLINF.SIF
