24 DEVICE/LABEL INITIAL VALUE SETTINGS
397
24
24 DEVICE/LABEL INITIAL VALUE SETTINGS
This function sets the initial values of devices and labels used in the program directly (not via the program) to the devices,
labels, and buffer memory areas of intelligent function modules.
• When using a Process CPU, refer to the following as well.
Page 322 LABEL INITIALIZATION FUNCTION
• When using a SIL2 Process CPU, refer to the following as well.
Page 605 FUNCTIONS
• When using a Safety CPU, refer to the following as well.
Page 535 FUNCTIONS
(1) If initial device values are used, a program to set data to the devices becomes unnecessary.
RnCPU
RnENCPU
RnSFCPU RnSFCPU
RnPSFCPU RnPSFCPU
RnPCPURnPCPU
(Standard) (Safety)(Standard) (Safety)
(Redundant)
(Process)
SM402
MOV H100 D0
MOV H2020 D1
(1)
CPU module
Device initial value
setting
Device memory
CPU module
To Next Page
