16.1 Out-of-group I/O Fetch
289
16
16.1 Out-of-group I/O Fetch
The access range to the controlled module is different from that to the non-controlled module. To fetch the data which cannot
be accessed, use the out-of-group I/O fetch function.
Accessing controlled module
The access range to the controlled module of the CPU module is the same as that to the single CPU system, and I/O refresh
for the controlled module and/or reading/writing to buffer memory of the intelligent function module are enabled.
Accessing non-controlled module
Access to the non-controlled module of the CPU module is limited to reading input (DX) and buffer memory of the intelligent
function module. Note that On/Off data of input (X)/output (Y) of the non-controlled module can be fetched using the out-of-
group I/O Fetch function. ( Page 290 Out-of-group I/O fetch setting)
: Accessible, : Not accessible
*1 Cannot read from CPU modules which are synchronized through the inter-module synchronization function.
Precautions
An error is not detected in reading input (DX) for the non-controlled module and buffer memory of the intelligent function
module.
Communication
method
Access target Access range
When "Import" is selected in
the settings for out-of-group I/O
fetch
When "Not Imported" is
selected in the settings for out-
of-group I/O fetch
Communication
through refresh
Input (X) Read to another
CPU module

*1
 (Non-processing)
Output (Y) Write to another
CPU module
 (Non-processing)
Read to another
CPU module

*1
The buffer memory of the
intelligent function module
Read  (Cannot be specified from
engineering tools)
 (Cannot be specified from
engineering tools)
Write
Link direct device Read  (Cannot be specified from
engineering tools)
 (Cannot be specified from
engineering tools)
Write
Communication
through direct
access
Input (DX) Read to another
CPU module

Output (DY) Write to another
CPU module
 (Non-processing)  (Non-processing)
Read to another
CPU module
 (Cannot be specified)  (Cannot be specified)
The buffer memory of the
intelligent function module
Read 
Write  (An error occurs in the CPU
module.)
 (An error occurs in the CPU
module.)
Link direct device Read  (An error occurs.)  (An error occurs.)
Write
