176
11 DATA LOGGING FUNCTION
11.2 Data Collection Conditions
■Specifying the monitored data
For monitored data, the following devices and labels can be specified.
*1
*1 When specifying the local device, global label, or local label, check the versions of the CPU module, engineering tool, and CPU Module
Logging Configuration Tool. ( Page 1008 Added and Enhanced Functions)
The data types that can be selected include bit/word (unsigned), word (signed), double word (unsigned), and double word
(signed).
*2 An index modified device and indirectly specified device cannot be specified.
*3 For bit devices, digit specification is not supported.
*4 For word devices, bit specification is allowed.
*5 To specify the local device, use "Program name/#Device name". (Example: "MAIN/#M1")
*6 To specify these devices with CPU Module Logging Configuration Tool, use T (contact): TS, ST (contact): STS, C (contact): CS, LT
(contact): LTS, LST (contact): LSTS, and LC (contact): LCS.
*7 The device can be collected by using the CPU module where the SFC function can be used. ( Page 1008 Added and Enhanced
Functions)
*8 A label with a name of 256 characters or less can be specified. When the local label is specified (program block name/label name), the
"program block name/" part is counted as the number of characters.
*9 Only labels in the read project of the engineering tool can be specified.
*10 Specify the label with "Program block name/Label name". (Example: "ProgPou/label_w1")
*11 Digit-specified labels cannot be specified.
*12 Bit specification is allowed.
*13 Only the contacts and current values can be specified.
*14 For the label of timer type and counter type, specify the element name. (S: contact, N: current value)
Global label example: "label_w1.S"
Local label example: "ProgPou/label_w1.S"
*15 Specify the array element. If the array element is not specified, it is handled as the start of the array ([0]). ( Page 969 Data)
*16 Specify the structure member. ( Page 969 Data)
Type Device
*2
Device Bit device
*3
X, Y, M
*5
, L, F, SM, V
*5
, B, SB, T (contact)
*5*6
, ST (contact)
*5*6
, C (contact)
*5*6
, LT
(contact)
*5*6
, LST (contact)
*5*6
, LC (contact)
*5*6
, FX, FY, Jn\X, Jn\Y, Jn\SB, Jn\B, BLn\S
*7
Word device
*4
T (current value)
*5
, ST (current value)
*5
, C (current value)
*5
, D
*5
, SD, W, SW, RD, R, ZR, Z,
FD, Un\G, Jn\W, Jn\SW, U3En\G, U3En\HG
Double-word device LT (current value)
*5
, LST (current value)
*5
, LC (current value)
*5
, LZ
Type Class Data type
Label
*8*9
Global label • VAR_GLOBAL
• VAR_GLOBAL_RETAIN
■Primitive data type/array
*15
•Bit
*11
• Word (signed)
*12
• Double word (signed)
• Word (unsigned)
*12
• Double word (unsigned)
• Timer type
*13*14
• Retentive timer type
*13*14
• Counter type
*13*14
• Long timer type
*13*14
• Long retentive timer type
*13*14
• Long counter type
*13*14
■Structure
*16
Local label
*10
•VAR
• VAR_RETAIN
