122
1 FUNCTIONS
1.9 File Transfer Function (FTP server)
FTP command
FTP command list
The FTP client side commands supported by the Ethernet-equipped module are shown below.
: Executable
*1
, : Not executable
*2
*1 The command may not be executed depending on the file type. ( Page 121 Files that can be transferred with FTP)
*2 If executed, the process completes abnormally.
*3 Shows the "Allow Online Change" setting in "FTP Server Settings" under "Application Settings". If an illegal command is executed while
write is prohibited during RUN, the process completes abnormally.
*4 Shows whether the command can be executed when the FTP communication port is specified as a remote password check target port
with the Ethernet-equipped module mounted station's remote password setting. For details on the remote password, refer to the
following.
( Page 174 Remote password)
*5 The Ethernet-equipped module is set to transfer the file automatically without conversion. (Binary code fixed)
Therefore, the file is transferred with binary code regardless of the "Communication Data Code" setting in "Own Node Settings" under
"Basic Settings".
*6 The parameter file and program file cannot be deleted when the CPU module is in the RUN state.
*7 Only the subcommands dedicated for the Ethernet-equipped module can be used. For the subcommands can be used, refer to the
following.
( Page 123 Subcommands usable with quote command)
Command Function CPU module status Remote password
STOP RUN Unlocked
*4
Locked
*4
Enable
*3
Disable
*3
binary
*5
Notifies that the file will be transferred without conversion.
bye Closes and ends the connection with the FTP server.
close Closes the connection with the FTP server.
delete Deletes the CPU module file.
*6
dir Displays the CPU module file information.
get Reads a file from the CPU module.
ls Displays the CPU module file name.
mdelete Deletes the CPU module file.
*6
mdir Stores the CPU module file information in the file.
mget Reads a file from the CPU module.
mls Reads a file from the CPU module.
mput Writes the file to the CPU module.
open Connects to the FTP server.
put Writes the file to the CPU module.
pwd Displays the current directory of the CPU module.
quit Closes and ends the connection with the FTP server.
quote Sends the FTP server's subcommand.
*7
rename Changes the CPU module file name.
user Inputs the user name and password for the Ethernet-equipped
module.
To Next Page
