1 FUNCTIONS
1.10 File Transfer Function (FTP Client)
135
1
1.10 File Transfer Function (FTP Client)
The CPU module becomes an FTP client and can execute file transfer with the FTP server connected to Ethernet using the
file transfer function instruction.
* 1
*1 To execute this function, an FTP server is required. For details on an FTP server, refer to the manual for the server used.
When the data logging function is used, a data logging file can be transferred to the FTP server by using the
data logging file transfer function. ( MELSEC iQ-R CPU Module User's Manual (Application))
Before executing the function, check the versions of the CPU module and engineering tool used. ( Page
406 Added and Enhanced Functions)
File transfer specifications
The following table summarizes the file transfer specifications of the file transfer function (FTP client).
Item Description
FTP server whose operation has been checked by Mitsubishi Microsoft

Internet Information Services(IIS)
Targe t O S:
•Microsoft

Windows

10
•Microsoft

Windows

8.1
•Microsoft

Windows

8
•Microsoft

Windows

7
Number of connectable FTP servers 1
FTP transfer mode Binary mode
SP.FTPPUT
SP.FTPGET
END
·
Ethernet
File transfer function instruction
CPU module (FTP client)
Retrieving a specified file
SP.FTPGET instruction
SP.FTPPUT instruction Sending a specified file
External device (FTP server)
