1 FUNCTIONS

1.12 Web Server Function

171

Error message

Display example of error messages

If an object of the user Web page is used incorrectly, a button to notify the user of an error is displayed at the upper left of the

object when the user Web page is displayed. The error message related to the common processing which is not limited to the

object is displayed at the upper left of the window.

Click the button to display the detailed information of the error.
