Operator user‟s manual
50/78
i) Once the system has completely been configured, it‟s recommended to export the
settings. When working as an O.T., the settings are not exported to an external device:
Click5000 will keep the easyphoto settings. See the „Import/ Export settings‟ chapter of
this manual. This way of work is useful when installing additional O.T‟s: all the previous
steps are required for every O.T., except the h) step, that can be avoided just importing
the settings from Click5000.
Basic and Advanced mode. A deeper view.
Basic mode: the Order Terminal (O.T.) number can be changed. This is useful, when
using a basic lan installation, to identify each easyphoto connected to a Flexilab system.
In this way, the basic connection parameters are changed automatically.
In this mode, Click5000 is supposed to be working with these parameters:
IP: 192.168.0.100
IP mask: 255.255.255.0
Gateway: 192.168.0.1
And the easyphoto with these ones (when O.T. number is „1‟):
IP: 192.168.0.201
IP mask: 255.255.255.0
Gateway: 192.168.0.1
Machine Name & Bluetooth ID: MT1-1
Initial order number: 1000
If O.T. number is changed, as instance, to „2‟, these parameters will be changed
automatically to these new ones, and so on:
IP: 192.168.0.202
IP mask: 255.255.255.0
Gateway: 192.168.0.1
Machine Name & Bluetooth ID: MT1-2
Initial order number: 2000
Advanced mode: manual configuration of all the net parameters such as machine
name, IP, Mask, Gateway IP, etc.
