(Note)
Set the
ORS2
orientation detector's direction (bit 8) and position loop detector's
direction (bit
E)
from the relationship between rotations of the motor and detector
by referencing the following mounting schematic.
1)
Encoder (bit 8, bit
E)
0: (+)
direction
1: (-)
direction
ncod
Belt
er
%
Motor
2)
Magnesensor (bit
8)
0: (+)
direction
1: (-)
direction
_
-
I
Reference
Reference
SetIS
Magnet
3) To perform the synchronous
tap operation without the spindle encoder,
should be set to 0.
bit E
-195-
