Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers
Foreword
• This manual contains text, diagrams and explanations which will guide the reader in the correct installation
and operation of the FX
1S
Series Programmable Controllers. It should be read and understood before
attempting to install or use the unit.
• Further information can be found in the FX Series Programming Manual II.
• If in doubt at any stage of the installation of an FX
1S
Series Programmable Controller always consult a
professional electrical engineer who is qualified and trained to the local and national standards which apply to
the installation site.
• If in doubt about the operation or use of FX
1S
Series Programmable Controller please consult the nearest
Mitsubishi Electric distributor.
• This manual is subject to change without notice.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
