3.2 FX
1S
RUN/STOP Control
RUN or STOP of the FX
1S
can be controlled by:
"
The RUN/STOP switch mounted next to the programming port.
#
A standard input (X0 to X17) defined by the system parameters.
$
Remotely from a personal computer or other programming peripheral.
Note
:The FX
1S
RUN/STOP switch works in parallel with the RUN input terminal. Please
refer to Table 3.2.
During remote operation the FX
1S
RUN/STOP status is determined by the most recently
operated control.
E.g. If the RUN/STOP switch is in RUN and a remote STOP is made from a personal
computer, the PLC can only be restarted with the RUN/STOP switch by first moving the
switch to STOP and then back to RUN.
Figure 3.2: RUN/STOP Input Wiring Diagram
Table 3.2: Run Status Table
RUN/STOP
SWITCH
➊
RUN INPUT
TERMINAL
FX
1S
MPU
STATUS
✔✔
RUN
✔✘
RUN
✘✘
STOP
✘✔
RUN
X0S/S 0V 24V X1 X0
RUN
➊

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
