Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Terminal Layouts 2
2-3
1
2
3
4
5
6
7
2.3 FX
1S
-**MT-DSS
Figure 2.3: Terminal Layouts, Transistor Outputs, DC Power
S/S
X1
- X0 X4 X6
FX
1S
-14MT-DSS
X5 X7
Y0 Y1 Y2 Y4
X3
X2
+V0 +V1
Y3 Y5
+V2
+
S/S
X1
- X0 X4
FX
1S
-10MT-DSS
X5
Y0 Y1 Y2 Y3
X3
X2
+V0 +V1 +V3+V2
+
S/S
X1
- X0 X4 X6
FX
1S
-20MT-DSS
X5 X7
Y0 Y1 Y2 Y3
X3
X2
+V0 +V1 +V3 +V4+V2
+
X11 X13
X10 X12
Y5
Y6
Y7
Y4
S/S S/S
-
S/S
X2 X4
FX
1S
-30MT-DSS
X3 X5
Y0 Y1 Y2 Y4
X1
X0
+V0 +V1
Y3 Y5
+V2
+
X7 X11
X6
X13 X15
X12X10 X14 X16
X17
Y6
Y7 Y11
Y10
Y14Y12
Y13
+V4
Y15
+V3

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
