Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Installation Notes 3
3-9
1
2
3
4
5
6
7
3.7 Termination of Screw Terminals
Terminal screws should be tightened to between 0.5 to 0.8 N
%
m. Terminal screws must be
secured to prevent a loose connection thus avoiding a malfunction.
The terminal screws for the FX
1S
Series PLC are M3.0. The crimp style terminal (see Figure
3.4 and 3.6) is suitable for use with these screws and should be fitted to the cable for wiring.
When installing 1 or 2 crimp terminals to a terminal, see explanation Figure 3.5 and 3.7.
However, 3 crimp terminals or more should not be installed to a single terminal.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
